Test & Check Kvant Clubmax 3400 FB4 Saturn 1
Zum Shop von gtTech: https://goo.gl/XiiMdp Kein Video mehr verpassen auf: http://www.youtube.com/subscription_center?add_user=airpool95 ---------------------------------------------------------------------------------------------- Technische Daten: Type: full-colour, semiconductor diode laser system Guaranteed optical output: 3400mW Suitable for: indoor/small outdoor laser shows and laser graphic displays Control signal: Ethernet, ArtNet, DMX, ILDA Scanning system: ScannerMAX 506 Compact | 40kpps @ 8° [see Options below] Safety: fully complies with the latest EN 60825-1, FDA regulations and TUV Laser Safety. Weight: 8.8kg Package includes: heavy duty flight case, power lead, 10M ILDA signal cable, E-STOP remote with 10M cable, set of 4 safety keys, interlock connector, CD with PDF manual. R | G | B [mW]: 920 | 900 | 1600 [*see note] Beam size [mm]: 3.5 x 4 Beam divergence: less than 1mrad [full angle] Modulation: analog, up to 50kHz Power requirements: 100-230V/50Hz Consumption: max. 350VA Operation temperature: 10-40 °C Ingress protection rating: IP54 System features: All the adjustments such as power output of each colour, X & Y axes invert, X & Y size and position, etc. are managed by inbuilt FB4 control system. Scanning system protection, daisy chain of emergency STOP signal for multiple system "one-hit" operation. Laser safety features: Keyed interlock, emission delay, magnetic interlock, scan-fail safety, V-RAD 506 mechanical shutter | reaction time less than 20ms, adjustable aperture masking plate. *Due to Advanced Optical Correction technology used in our laser systems the optical power output of each laser colour within the system may slightly differ from the specification of respective laser module(s) installed. This does not affect the total guaranteed power output. Dimensions: Length: 276 Width: 255 Height: 168 ----------------------------------------------------------------------------------------------- Musik: Epidemic Sound
